Locating Ring

Get a Price/Quote

MOQ : 100 Pieces

Locating Ring Specification

Molding Material
Plastic

Life Span
Up to 1 Million Shots

Mold Base
Steel

Cavity
Single or Multi Cavity

Shaping Mode
Injection Mould

Material
High Grade Tool Steel

Tolerance
0.01 mm

Mould Weight
0.5 kg - 2 kg

Mould Life
500,000 Shots

Application
Injection Moulding Tooling

Shape
Round

Heat Treatment
Yes

Corrosion Resistance
High

Installation
Press Fit or Bolt On

Diameter Range
38 mm - 100 mm

Surface Finish
Precision Ground

Standard
DIN / JIS / Customized

Hardness
HRC 48-52

Packaging Type
Boxed or Customized

Usage
For Fixing Mould in Injection Moulding Machine

Locating Ring Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Average Load Time
5-10 Seconds

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Locating Ring

Experience the monumental precision of our Round Locating Rings-specially engineered for injection moulding tooling. Made from pristine high-grade tool steel, their unprecedented accuracy (0.01 mm tolerance) guarantees perfect mould alignment and repeated, reliable performance. With a remarkable hardness of HRC 48-52 and advanced heat treatment, they offer high corrosion resistance and a lifespan up to 1 million shots. Get it now from a leading supplier, service provider, and trader in India-buy online and have your boxed or customized solution delivered directly.

Key Features and Versatile Applications

Our Locating Rings are designed with precision surface finishes for seamless fit and reliable alignment on steel mold bases. Engineered for both press fit or bolt-on installations, they are ideal for securing moulds in injection moulding machines. The rings cater to various molding materials, plastic cavity options, and diverse shaping modes, suiting both single and multi-cavity setups. Their robust construction delivers stable, long-lasting performance across multiple industrial applications.

Robust Supply Ability and On-Time Delivery

Benefit from our high rate of supply, designed to meet bulk industrial needs without delay. Each order is handled with meticulous care-your precision locating rings are packed securely, either boxed or customized, before being handed over for prompt dispatch. With a dependable delivery time and sales processed via transparent FOB port arrangements, customers enjoy an efficient purchase experience at a competitive sale price.

FAQ's of Locating Ring:

Q: How do I install the Locating Ring in an injection moulding machine?

A: The Locating Ring can be installed by either the press fit or bolt-on method, ensuring secure and precise mould alignment on the injection moulding machine.

Q: What is the lifespan of the Locating Ring and how many shots can it withstand?

A: Our Locating Rings deliver a mould life of up to 500,000 shots and an overall lifespan of up to 1 million shots due to their superior hardness and heat treatment.

Q: Where does the Locating Ring offer the best corrosion resistance?

A: Thanks to its advanced surface finish and high-grade tool steel construction, the Locating Ring displays exceptional corrosion resistance in high-moisture and high-temperature moulding environments.

Q: What applications can benefit from using your Locating Ring?

A: These rings are ideal for fixing moulds in injection moulding machines used across plastics manufacturing, automotive, and electronics sectors, for both single and multi-cavity molds.

Q: How can I buy the Locating Ring online and what delivery options are available?

A: You can easily place your order online through our platform. We offer boxed or custom packaging, and swift delivery via trusted FOB port shipping channels across India.
